2/3U 800W x 2 Short Industrial Redundant PSU Platinum with Pmbus

PCICASE Model No: PIZ2080R-92-ACB
Manufacturer Model No: R2CU5801A
UK Stock
Key Features
  • Certified to 62368-1
  • 800 watt 92+ Platimum PSU For Energy Efficency
  • Support Bidirectional Fan Design
  • Enviromental Compliance: RoHS, WEEE, REACH
  • EMI/RFI: CISPR22;CLASS A
  • Protection: OVP OCP OTP SCP
  • Safety: UL/cUL, TUV, FCC, CCC, BSMI, KC, CB, CE, BIS
  • Short Depth Design
  • Cost Effective
  • Suitable For Industrial PC & Server Storage Chassis
House Specification
  • Model - R2CU5801A
  • Option - P4QA
  • REV - A00
  • FRU - APM12V0106
  • Limited use Module Watt - 800W
  • Cable Layout
    • 2 x Molex 200mm
    • 2 x Mini Molex 200mm
    • 1 x SATA + SATA 200mm + 100mm
    • 1 x PMBUS 400mm
    • 1 x 24 pin 150mm
    • 2 x 8 pin 150mm
    • 1 x 4 pin 150mm
    • 1 x 8pin PCIe 250mm
    • 2 x Connectors for 12G Backplane


Module Dimensions (mm)

73.5 x 185 x 40

Module Input Specification
  • Model:-  R1CA2801A
  • Option P00A
  • Rev - A03
  • FRU - APM12V0302
  • Input Voltage:- 90-264Vac 180-300Vdc
  • Input Frequency:- 47-63Hz
  • Switching Power Supply
  • Input Currency
    • 4.5@100-127Vac/2.5A@200-240Vac
    • 2.5A@240Vdc
    • 5.5A@100-127Vac/2.5A@200-240Vac
    • 2.5A@240Vdc
    • 7A@100-127VAC/3.5A@200-240Vac
    • 3.5A@240Vdc
    • 10A@100-127Vac/5A@200-240Vac
    • 5A@240Vdc
    • 10A@100-127Vac/8A@200-240Vac
    • 6A@240Vdc
DC Output Specification
  • Voltage - +12V
  • Regulation - +/-5%
  • High Line Max Load - 66.7A
  • Ripple & Noise - 120mV p-p
*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.



Module Datasheet Module Datasheet


 PIZ2080R-92-ACB Module.pdf



Housing Datasheet Housing Datasheet


 PIZ2080R-92-ACB-Housing.pdf
