4U GPU Tower / Rack-Mountable Chassis with 8 x 3.5” swappable SAS/SATA HDD Tray

PCICASE Model No: TSC-CS-W45
Manufacturer Model No: CS-W45
Coming Soon
  • Supports motherboard size up to ATX
  • 2 x 2.5” HDD Bay (Internal)
  • I/O depends on motherboard specification
  • 1 x Full-Height/Half-Length expansion slot
M/B Form Factor Mini-ITX, Micro-ATX, ATX, E-ATX motherboard
Dimension (WxDxH) 178 x 647 x 452 mm (7.0” x 25.5” x 17.8”)
Color Black
Processor Support Single and Dual Intel/AMD Processors
Drive Bay External: 8 x 3.5” Swappable SAS/SATA Drive Tray
Internal: 3 x 5.25” Internal Drive Bay (90o Rotatable Drive Cage)
Backplane 8-port 12Gbps SAS/SATA to 2-port Mini-SAS HD with SGPIO
Expansion Slot 8 x Full-Height/Full-Length
System Cooling 4 x 80mm Swappable PWM Fans (Middle)
1 x 92mm PWM Fans (Rear)
2 x 80mm PWM Fans (Outer)
Front Panel 2 x USB 3.0 (Option: USB2.0)
1 x Power Button
1 x Reset Button
1 x Power LED
1 x HDD Activity LED
2 x Network LEDs
1 x Overheat LED
1 x System Fail LED
Security Intrusion Switch, Front Door Key Lock
Power Supply PS/2 ATX Power Supply (D190 x W150 x H86mm, option)
Weight Net Weight 24.04kg (53lbs); Gross Weight 25.4Kg (56lbs)
Environment Operating Temperature: 5o ~ 35oC (41o ~ 95oF)
Storage Temperature: -40o ~ 70ºC (-40o ~ 158ºF)
Operating Humidity: 8% ~ 90% RH (non-condensing)
Storage Humidity: 5% ~ 95% RH (non-condensing)
