1U 1600W Titanium OEM Fitted PSU Module

PCICASE Model No: CPR-1621-6M1
Manufacturer Model No: CPR-1621-6M1

Key Features

  •  80 PLUS Titanium
  • Support PMBus 1.2
  • Internal ORing
  • N+1 Redundant
  • Digital Power Supply
  • Cold Redundancy
  • Smart Ride Through
  • Black Box Recorder
  • Automatic Firmware Update
  • High Power Density 39.7 W/in3
  • Active Power Factor Correction
  • Intel Standard CRPS Form Factor
  • Closed Loop System Protection (CLST)

DIMENSIONS
Dimension´╝Ü203 x 73 x 40 mm (D x W X H)

TOTAL MAX POWER
1000 W @ 100 - 140 Vac
1600 W @ 180 - 240 Vac

INPUT SPECIFICATIONS
Input voltage 90 - 264 Vac
Input frequency 47 - 63Hz
Input current 100 - 140 V / 13 - 9.0 A
180 - 240 V / 11 - 8.0 A

GENERAL SPECIFICATIONS

Hold-up time 11ms @ 70% Load
Efficiency at least 96% @ 50% load
MTBF 50,000 hours at 50 degree C

ENVIRONMENTAL SPECIFICATIONS

Temperature 0 to 50 degree C Operating
Altitude 10,000 feet Operating
Relative humidity 20% to 85% RH Operating

OUTPUT SPECIFICATIONS

Voltage +12V +12Vsb
Regulation ±5% ±5%
Max Load 1000W : 83A
1600W : 133A 3.5A
Ripple & Noise 120mVp-p 120mVp-p
