Form Factor
1x 5.25" Drive Bay Width Size
Support HDD Type
2 X 2.5” NVMe U.2 SSD (Height Up To 15mm) (PCIe3.0/4.0 X4 32/64Gbps)
4 X 2.5” SATA I, II, III & SAS I, II, III (12Gbps) HDD/SSD(* Up To 7mm)
Interface
MiniSAS HD (SFF8643) Connector X 2
7pin SATA Connector X 4
15pin Power Connector X 2
3pin Cooling Fan Jumper X 2
LED Indication
Power On- Green
HDD Access- Orange Blinking
Security Design
Metal Key Lock
Mechanical Lock
Classified Digital Number For Choice
Material
Metal Frame & Stainless HDD Tray
Fan
N/A
Operating System
Windows/ Linux/Mac
Product Dimension
160(L) X 144(W) X 40(H) Mm
Product Weight
1.1kg
